| CPU Model | AMD Ryzen V1500B |
|---|---|
| CPU Quantity | 1 |
| CPU Architecture | 64-bit |
| CPU Frequency | 4-core 2.2 GHz |
| Hardware Encryption Engine (AES-NI) | YES |
| System Memory | 4 GB DDR4 ECC SODIMM |
| Memory Module Pre-installed | 4 GB (4 GB x 1) |
| Total Memory Slots | 2 |
| Maximum Memory Capacity | 32 GB (16 GB x 2) |
| Notes | Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion. For more information about the recommended memory configurations, please check the Hardware Installation Guide of your Synology product. |
| Drive Bays | 6 |
| Maximum Drive Bays with Expansion Unit | 16 (DX517 x 2) |
| M.2 Drive Slots | 2 (NVMe) |
| Compatible Drive Type* (See all supported drives) | 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD M.2 2280 NVMe SSD |
| Hot Swappable Drive* | YES |
| RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| USB 3.2 Gen 1 Port* | 3 |
| eSATA Port | 2 |
| PCIe Expansion | 1 x Gen3 x8 slot (x4 link) |
| Internal Drives | Btrfs EXT4 |
| External Drives | Btrfs EXT4 EXT3 FAT NTFS HFS+ exFAT |
| Size (Height x Width x Depth) | 166 mm x 282 mm x 243 mm |
| Weight | 5.1 kg |
| System Fan | 92 mm x 92 mm x 2 pcs |
| Fan Speed Mode | Full-Speed Mode Cool Mode Quiet Mode |
| Easy Replacement System Fan | YES |
| Brightness Adjustable Front LED Indicators | YES |
| Power Recovery | YES |
| Noise Level* | 25.2 dB(A) |
| Scheduled Power On / Off | YES |
| Wake on LAN / WAN | YES |
| Power Supply Unit / Adapter | 250 W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 51.22 W (Access) 25.27 W (HDD Hibernation) |
| British Thermal Unit | 174.77 BTU/hr (Access) 86.22 BTU/hr (HDD Hibernation) |
| Operating Temperature | 0?C to 40?C (32?F to 104?F) |
| Storage Temperature | -20?C to 60?C (-5?F to 140?F) |
| Relative Humidity | 5% to 95% RH |
| Certification | FCC CE BSMI EAC CCC KC VCCI RCM |
| Warranty | 3-year hardware warranty, extendable to 5 years with Extended Warranty Plus |
| Environment | RoHS Compliant |
| Packaging Content | Main Unit X 1 Accessory Pack X 1 AC Power Cord X 1 RJ-45 LAN Cable X 2 Quick Installation Guide X 1 |
| Optional Accessories | DDR4 ECC SODIMM: D4ES01-4G/D4ES01-8G/D4ECSO-2666-16G Expansion Units: DX517 3.5" SATA HDD: HAT5300/HAT3300 2.5" SATA SSD: SAT5210 M.2 2280 NVMe SSD: SNV3410 25GbE Network Interface Card: E25G21-F2 10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1 Surveillance Device License Pack |
